Tracing - Introducing OpenTelemetry to the Browser

Mackerel uses the OpenTelemetry mechanism (instrumentation) to collect data.

This page explains how to send data from browser-based web applications to Mackerel.

OpenTelemetry for the Browser

OpenTelemetry provides an SDK for browsers (@opentelemetry/sdk-trace-web).

You can use this SDK to measure performance data such as page load times and user interactions.

opentelemetry.io

Prerequisites

To post traces from the browser to Mackerel, you need a client token. Please create a client token from the dashboard in advance.

For more details about client tokens, refer to the following page.

Client Tokens

Implementation

You can implement Mackerel's tracing feature by following the steps below.

1. Add packages
2. Initial setup
3. Configure sampling

1. Add packages

Install the following packages.

npm install @opentelemetry/api \
  @opentelemetry/sdk-trace-web \
  @opentelemetry/sdk-trace-base \
  @opentelemetry/exporter-trace-otlp-proto \
  @opentelemetry/instrumentation \
  @opentelemetry/instrumentation-document-load \
  @opentelemetry/instrumentation-fetch \
  @opentelemetry/context-zone \
  @opentelemetry/resources \
  @opentelemetry/semantic-conventions

2. Initial setup

To send OpenTelemetry data to Mackerel, you need to set the following items.

• Exporter
• resource

For example, the following will allow you to send data from the SDK to Mackerel.

import { WebTracerProvider } from '@opentelemetry/sdk-trace-web';
import { OTLPTraceExporter } from '@opentelemetry/exporter-trace-otlp-proto';
import { SimpleSpanProcessor } from '@opentelemetry/sdk-trace-base';
import { DocumentLoadInstrumentation } from '@opentelemetry/instrumentation-document-load';
import { FetchInstrumentation } from '@opentelemetry/instrumentation-fetch';
import { ZoneContextManager } from '@opentelemetry/context-zone';
import { resourceFromAttributes } from '@opentelemetry/resources';
import { registerInstrumentations } from '@opentelemetry/instrumentation';
import {
  ATTR_SERVICE_NAME,
  ATTR_SERVICE_VERSION,
} from '@opentelemetry/semantic-conventions';

// Define ATTR_DEPLOYMENT_ENVIRONMENT_NAME separately
const ATTR_DEPLOYMENT_ENVIRONMENT_NAME = 'deployment.environment.name';

// Exporter configuration using Client Token
const exporter = new OTLPTraceExporter({
  url: 'https://otlp-vaxila.mackerelio.com/v1/traces',
  headers: {
    'X-Mackerel-Client-Token': 'YOUR_CLIENT_TOKEN_HERE',
  },
});

// TracerProvider configuration
const provider = new WebTracerProvider({
  resource: resourceFromAttributes({
    [ATTR_SERVICE_NAME]: 'my-web-app',
    [ATTR_SERVICE_VERSION]: 'vX.Y.Z',
    [ATTR_DEPLOYMENT_ENVIRONMENT_NAME]: 'production',
  }),
  spanProcessors: [new SimpleSpanProcessor(exporter)],
  // Consider using BatchSpanProcessor in production
  // spanProcessors: [new BatchSpanProcessor(exporter)],
});

provider.register({
  // Using ZoneContextManager supports asynchronous operations
  contextManager: new ZoneContextManager(),
});

registerInstrumentations({
    instrumentations: [
    // Using DocumentLoadInstrumentation to measure page load performance
    new DocumentLoadInstrumentation(),
    // Using FetchInstrumentation to measure the performance of HTTP requests made with the Fetch API
    new FetchInstrumentation()
],
});

This example sets the following items.

• Exporter
  • url
    • Setting the url to https://otlp.mackerelio.com/v1/traces sends data to Mackerel.
  • headers
    • Set the client token in the X-Mackerel-Client-Token header.
    • For how to create a client token, refer to Client Tokens.
• resource
  • By setting ATTR_SERVICE_NAME to your service name, you can identify the source of the data.
  • As of May 2025, ATTR_DEPLOYMENT_ENVIRONMENT_NAME is included in @opentelemetry/semantic-conventions/incubating, but since this package is unstable, it is defined separately instead of importing it, as recommended by Unstable SemConv.

3. Configure sampling

Traces from browsers can generate a large volume proportional to the number of users. To prevent exceeding rate limits and increased costs, configuring sampling is recommended.

By using TraceIdRatioBasedSampler, you can configure it to send only a certain percentage of traces. Add the sampler option to the initial setup code described above.

import { TraceIdRatioBasedSampler } from '@opentelemetry/sdk-trace-base';

const provider = new WebTracerProvider({
  sampler: new TraceIdRatioBasedSampler(0.1), // Record only 10% of traces
  // ... resource and spanProcessors configuration from above
});

Adjust the sampling rate according to the scale of your application and the volume of traffic.

Other instrumentation approaches are also available. For details, refer to the OpenTelemetry documentation.

opentelemetry.io
